Setup
Operating Instructions M-TYPE DELTA - 01.0 - 08/2019 159
Fig. 77: Assembling the tilt sensor (2)
The magnet and the sensor face one another when the machine
head is erected.
7.10 Changing the handwheel
The handwheel that ships with the machine is the large handwheel.
The large handwheel can be replaced with the included small
handwheel.
Important
When assembling the small handwheel, the included cover
must be positioned above the handwheel and tightened on
the machine.
