Set the switches, levers and controls listed below to the specified positions when the
screed has reached its operating temperature and a sufficient amount of material lies
in front of the screed:
- Push the drive lever (14) all the way to the front and start driving.Screed floating
position is activated now.
- Observe the distribution of the material and adjust the limit switches if necessary.
- Set the compacting elements (tamper and/or vibration) according to the required
compaction ratio.
- Let the paving master check the layer thickness after 5–6 meters and correct if nec-
essary.
Carry out the check in the area of the drive chains or wheels as the screed tends to
level an uneven ground. The reference points for the layer thickness are the drive
chains or wheels.
The basic setting of the screed must be corrected when the actual layer thickness de-
viates significantly from the values indicated by the scales (see the operating instruc-
tions for the screed).
A
The basic setting is for asphalt material.
Item Switch Position
1 Machine movement fast/slow slow („tortoise“)
2 Preselector regulator On / Off On (at the bottom)
3 Engine RPM (o) Maximum
4 Screed stop Auto
5 Screed position to floating position.
6 Vibrator (o)Auto
7 Tamper (o)Auto
8 Left/right auger Auto
9 Left/right feeder Auto
10 Speed regulator, tamper about 40-60 divisions
11 Vibration speed regulation about 40-60 divisions
12 Feeder Auto
13 Auger Auto
