Dynapac F 121 C User Manual

D 3.1 14
D_3.1_01_GB.fm 14-16
Front and side window (o) (103)
The front window can be folded up for
the maintenance works performed at the
tank.
- Fold the front window by its handle (A)
and lock it on the RH and LH sides
with the two locks (B) in the upper po-
sition.
Additional functions:
- If necessary, turn on the windscreen
wipers on the RH and LH sides (C).
- Fold up the side window (D) at its cle-
vis (window frame) and the push the
driver's seat out.
Wetterhaus.eps
(o)
A
C
D
B
