F 4.2 3
F_4.2_01_GB.fm 3-6
1.2 Points of maintenance
Auger - outer bearing (1)
The grease nipples (A) are located on
each side on the top of outer bearing.
These nipples must be lubricated each
time when work is finished.
A
The outer bearings of the auger shall be
lubricated when hot, so that the eventual
bitumen residues are expelled.
Auger middle bearing (2)
Lubrication of central bearing (A) is per-
formed on the LH-side of the auger.
To do so, the bevel gear unit must be
pulled off.
A
The central bearing shall be lubricated
when hot, so that the eventual bitumen
residues are expelled.
Schneckaula_Dyn.tif
A
F0015_A1.TIF
A
