Electric setting of the transportation

volume of the conveyor (o) (88)

With this the transport volume of the

conveyor can be adjusted when me-

chanical limit switch or ultrasonic sensor

is used.

- The „0“ position of the scale corre-

sponds to the smallest adjustable vol-

ume.

- RH-side conveyor: (88a)

- LH-side conveyor: (88b)

F0091_A1.EPS

(o)

85d

88a

88b
