2.3 Mechanical adjustment with ratchet
(optional)
- Set the ratchet direction lever to clock-
wise or anticlockwise direction. Turn-
ing anticlockwise lowers the auger,
turning clockwise lifts the auger.
- Set the desired height by alternatingly
adjusting the right-hand and the left-
hand side.
- The actual height can be read on scale
(1) in cm or inch (LH side column:
inch, RH side column: inch).
2.4 In case of hydraulic adjustment (op-
tion)
- Determine the currently set height of
the auger crossbeam (left and right)
by means of the scale (1).
F0116_A1.EPS
1
F0117_A1.EPS
1
