Dynapac F 121 C - Material Compartment (Hopper); Material Conveying; Material Distribution

B 16
B_F121C_F141C_02_GB.fm 16-24
5.12 Material compartment (hopper)
5.13 Material conveying
5.14 Material distribution
Volume about 6.0 m
3
= about 13.0 t
Minimum inlet height, center 520 mm
Minimum inlet height, outside 595 mm
Conveyors Left and right auger separately controllable
Drive Hydrostatic, continuously controllable
Conveying volume controller Fully automatic via configurable switching points
Augers Left and right auger separately controllable
Drive
Hydrostatic external drive, continuously controlla-
ble
independent from the conveyor
Auger halves can be switched to opposite direc-
tions
Conveying volume controller Fully automatic via configurable switching points
Auger height adjustment
- mechanically via chain
- mechanically (option)
- hydraulically (option)
Auger extension With extension parts (see auger extension chart)
