Dynapac F 121 C User Manual

B 13
B_F121C_F141C_02_GB.fm 13-24
5.6 Performance data F 121 C
Screed used
Basic width
(without cut-off shoes)
minimum paving width
(with cut-off shoe)
continuously hydraulically
adjustable up to
Maximum paving widths
(with attachments)
VB 510 T/TV 2,55 2,00 5,10 8,10 m
VB 510 T/TV+ 2,55 2,00 5,10 * m
VB 600 T/TV 3,00 2,45 6,00 8,20 m
VB 600 T/TV+ 3,00 2,45 6,00 * m
SB 1250 T/TV 3,00 * m
Travelling speed 0 - 4,5 km/h
Working speed 0 - 23 m/min
Layer thickness 0 - 300 mm
Max. grain size 40 mm
Theoretical paving performance 600 t/h

Dynapac F 121 C Specifications

General

Brand	Dynapac
Model	F 121 C
Category	Construction Equipment
Language	English
