5 Technical data, standard configuration

5.1 Dimensions (all dimensions in mm)

For the technical data of the screed, see the operating instructions of the screed.


6505*

1979

1600

3100

2900

3600

1988

3388

305

2550

487

2606

*VB510 T/TV
