F 6.0 6
F_6.0_01_GB.fm 6-8
High pressure filter (3)
Replace the filter cartridge when the
maintenance indicator (A) turns red.
- Unscrew filter house (B).
- Remove the filter cartridge
- Clean the filter house.
- Insert the new filter cartidge.
- Replace the seal ring of the filter hous-
ing.
- Turn on the filter housing by hand and
tighten it using a wrench.
- Start the trial operation and check the
tightness of the filter.
A
Replace the seal ring whenever the filter
cartridge is replaced.
A
After the replacement of the filter car-
tridge the red signal of the maintenance
indicator (A) automatically reverts to
green.
B
A
