Item Designation Brief description
5Starter
Starting is only possible when the drive lever is in the neutral
position. All emergency stop buttons (on the operating panel
and the remote controls) must be pulled up.
6
Machine drive
fast/slow
Hare: Travelling speed
Tortoise: Working speed for laying
7Horn
Use it as a sound alarm in case of imminent danger and be-
fore starting!
8
Preselector of trac-
tion drive
This sets the speed, which the machine must achieve with the
full swing of the drive lever.
A
The scale approximately corresponds to the speed in
m/min (when laying).
9
Drive lever
(forward)
For switching on the paver finisher functions and for continu-
ously regulating the traction speed – forward or reverse.
Zero position: starting is possible; engine at idling speed; no
traction drive; secured against inadvertent starting.
For turning out, pull up the ring (9a).
Depending on the position of the drive lever, the following
functions can be activated:
- position 1: the engine runs at the preset speed
(see Engine speed setting).
- position 2: feeder and auger On.
- position 3: screed movement (tamper/vibrator) turned on;
traction drive engaged; increase speed until im-
pact.
Use the preselector to set the maximum speed.
10 Not used
11 Not used
