D 1.4 17
D_1.4_01_GB.fm 17-22
Item Designation Brief description
35 has no function
36
Hydraulic oil ther-
mometer
Normal display up to 85 °C = 185 °F.
m
In case of higher temperature stop the machine, (set
drive lever to neutral position), and let the engine cool
at idling speed. Find the cause and eliminate the fault.
37
Alarm light (red)
„Water in the fuel“
This light is on, if the water separator of the fuel system has
established a too high water level.
m
In order to avoid the damage of the traction engine
drain the separated water immediately according to the
operation manual.
A
The fault is indicated together with the „Error message“
light.
38
Error message
(yellow)
It indicates that a fault has occurred in the traction engine. De-
pending on the type of the fault the operation of the machine
can be continued temporarily, or in case of a major fault it
must be stopped immediately to prevent further faults.
All the faults shall be eliminated as soon as possible!
A
The error message can be queried using button (13).
A
After the ignition is turned on, the light is on for a few
seconds for check-up.
39
High beam head-
light control lamp
(blue)
It is on, when the high beam headlight is switched on (at the
ignition switch).
f
Avoid blinding the oncoming traffic!
40 Not used
41
Stopping the en-
gine
It is on if the engine cannot be started (e.g. the emergency
stop button was depressed).
A
In such a case see Chapter „Operating failures“.
42
Indicator light of
engine tempera-
ture (red)
It is lit on, when the engine temperature is too high.
m
The output of the engine drops automatically. (Further
travel remains possible). Stop the paver finisher, (set
drive lever to neutral position), and let the engine cool
at idling speed. Find the cause and if necessary elimi-
nate it (see Chapter „Operating Faults“). Upon cooling
down to normal temperature, the engine will work
again at full capacity.
A
The fault is indicated together with the „Error message“
light.
