D 1.4 19
D_1.4_01_GB.fm 19-22
Item Designation Brief description
43
Oil pressure indica-
tor for the hydraulic
traction drive (red)
It must go out soon after start-up. Consider the time of warm-
ing up. The hydraulic oil may be too cold and rigid.
m
If the light does not go dark, do not turn on the trac-
tion drive.
A
The lamp goes out at a pressure of 2.8 bar = 40 psi.
44
Oil pressure indica-
tor for the Diesel en-
gine (red)
m
It is on, when the oil pressure is too low.
Stop the engine immediately!.
See the further possible faults in the operating in-
structions for the engine
A
The fault is indicated together with the „Error mes-
sage“ light.
45 has no function
46
Battery charge indi-
cator (red)
Must go out after starting when the engine revs up.
- Switch off the engine.
47 Not used
48 Not used
49 Service hour meter
The service hours are counted by the machine with running
engine.
Daily maintenance of the paver finisher (see chapter F)
50 Fuel gauge
Always heed the fuel gauge.
m
Do not completely empty the diesel tank! Otherwise,
the entire fuel system must be ventilated.
51 Not used
52 RPM meter (o)
The speed is displayed in revolutions per minute (rev/min).
A
The RPM can be modified with the speed regulator.
53 Fuse box I.
A
For assignment of fuse strips, refer to chapter F.
54 Fuse box II.
A
For assignment of fuse strips, refer to chapter F.
