D 4.6 3
D_4.6_01_GB.fm 3-38
Auger covers
For larger working widths, the walkway
plates must be extended and the auger
tunnels must be covered.
Screed covers and walkways
For larger working widths, the walkway
plates must be extended.
Hinged walkway plates must be swung
down.
Check that the side shields, the side
plates and the covers are securely
seated.
Screed transport safeguard
When the screed is lifted, it must be
possible to push the locking rods side-
ways into the recesses in the cross-
beams using the lever beneath the seat.
Hopper transport safeguard
When the hopper is closed, it must be
possible to fold the catches over the
lock studs on the two halves of the hop-
per.
Protective roof
Both locking bolts must be in the pro-
vided bore hole.
Miscellaneous:
- Engine hood
- Lateral flaps
Check that the hoods and flaps are
securely seated.
Accessories:
- Wedges
- Warning triangle
- First-aid kit
The accessories must be in the pro-
vided holders.
Check! How?
