D 3
D F6C.GB 3-50 0504
Item Designation Brief description
1
Steering potenti-
ometer
The steering wheel movement is transferred electrohydrauli-
cally.
If the straight-ahead travel control fails (position"0“ =
straight-ahead), fine-tuning can be performed using the
adjustment function for straight-ahead travel.
For turning on the spot, refer to switch (turning on the
spot).
2
Latch for operat-
ing panel
For securing the movable operating panel against inadvertent
movement.
- Turn the knurled screw at the desired location into the des-
ignated notch and secure with the knurled nut.
When not secured, the operating panel can move.
Danger of accidents during transportation!
3
Latch for operat-
ing panel
In the case of seats that can be swung out beyond the ma-
chine contour (option), the operating panel can also be moved
beyond the basic width of the paver finisher.
Pull out the latch and move the operating panel;
let the latch engage again.
An unlatched operating panel can slide out of position.
Danger of accidents during transportation!
4 Lighting
Lights up instrument panel A/B when the parking light is
switched on.
