D 7
D F6C.GB 7-50 0504
Item Designation Brief description
12
Ignition lock and
light switch
Key positions:
1 Ignition on
2 Parking/rear lights, instrument panel illumination,
working lights (if applicable)
3 Not in use
4 Not in use
To overcome the lock between positions 2 and 3, press
in the key.
Turning the key to the right = parking light
13 Horn
Press in the case of emergencies and to indicate when the
machine starts to move!
14
Emergency stop
button
Press in an emergency (danger to persons, possible collision
etc.)!
- Pressing the emergency stop button switches the engine,
the drives and the steering system off.
Making way, lifting the screed or other actions are then no
longer possible! Danger of accidents!
- The emergency stop button does not shut off the gas heat-
er system (O).
Close the main shut-off valve and the valves on the bottles
by hand!
- In the case of electrical malfunctions, the engine must be
turned off manually at the leverage of the injection pump.
To restart the engine, the button must be pulled out again.
15 not in use
