Item Designation Brief description
20 not in use
21
Deactivation of
floating position
„Deactivation of floating position“ is used to lock the screed
hydraulics to keep the screed from sinking into the material
when the paver finisher is at a standstill (intermediate stop).
A: automatic when the drive lever is in the central position 1
- Position C is used for setting up the paver finisher, position
A for paving.
C: permanently deactivated
22
Screed position
A: Lift screed
B: Hold screed (position for inserting the screed transport
safeguard (90))
C: Lower screed and assume the „floating position“
$
During paving, the screed must always be in the float-
ing position. This also applies to intermediate stops
and truck changes when the automatic screed stop
(21) is used.
