D 19
D F6C.GB 19-50 0504
Item Designation Brief description
40 not in use
41
Oil pressure indi-
cator lamp for the
diesel engine (red)
Must extinguish shortly after starting the engine.
$
Switch the engine off immediately if the lamp does not
go out.
For further possible faults, refer to the operating in-
structions for the engine.
42
Engine tempera-
ture indicator (red)
Lights up when the engine temperature is too high.
$
Stop the paver finisher (drive lever to the centre posi-
tion), let the engine cool down while idling. Determine
the cause and correct it if necessary (see the section
„Malfunctions“). After cooling down to normal tempera-
ture, the engine will run with full performance again.
43
Battery charge in-
dicator (red)
Must go out when the engine revs up after the start.
- Switch off the engine.
44 not in use
45
Operating hours
counter
Operating hours are only recorded while the engine is run-
ning.
Heed the maintenance intervals (see chapter F).
46 Fuel gauge
Always heed the fuel gauge.
$
Do not completely empty the diesel tank! Otherwise,
the entire fuel system must be ventilated.
47 RPM meter ( & ) Indicates the engine speed in rpm.
48
Engine tempera-
ture
Green area: normal temperature.
$
Stop the paver finisher (drive lever in the centre posi-
tion) when the display is near or in the red area, let the
engine cool down while idling. Determine the cause
and correct it if necessary (see the section „Malfunc-
tions“).
49 Fuse box I

For the fuse assignment,
see chapter F.
50 Fuse box II

For the fuse assignment,
see chapter F.
