Dynatest FWD - Trailer Specifications

2017.06.19 FwdMan2.8.17.docx
11-86
11.2 Trailer Specifications
8002 FWD Trailer
8082 HWD Trailer
Max. permissible weight
1200 kg (2,600 lbm)
(single axle)
1300 kg (2,800 lbm)
(tandem axle)
2,000 kg (4,400 lbm)
(tandem axle (standard))
Tire size
165-13”
185 R14 C
Tire pressure
2.8 bar (40 psi) cold
2.8 bar (40 psi) cold
Max. recommended driving
speed
70 km/h (45 mph)
70 km/h (45 mph)
Total length (max.)
4.35 m (171”)
4.45 m (175”)
Total width (max.)
1.65 m (65”) (single axle)
1.68 m (66”) (tandem axle)
1.78 m (70”)
Total height (max. during
driving)
1.40 m (55”)
1.45 m (57”)
Towing ball diameter (of towing
vehicle hitch)
50 mm OR 50.8 mm
(1-31/32” OR 2”)
50 mm OR 50.8 mm
(1-31/32” OR 2”)
Optimum height of tow ball
(ground to ball centre), loaded
with 100 kg (220 lb)
480 mm - 500 mm (19 - 20”)
480 mm - 500 mm (19 - 20”)
Hyd. oil quality
“Shell” Tellus Oil T37 or
“Exxon” Univis N46
“Shell” Tellus Oil T37 or
“Exxon” Univis N46
Hyd. system capacity
approx. 10 litres
(approx. 2.5 gal.)
approx. 13 litres
(approx. 3.5 gal.)
Approx. falling height range
of the drop weight
50-390 mm (2-15.3”)
50-390 mm (2-15.3”)
Loading plate diameter(s)
300 & 450 mm
(11.8 & 17.7”)
300 & 450 mm
(11.8 & 17.7”)
Range of distances of movable
raise/lower bar deflector holders
(from loading centre)
185-2450 mm
185-2450 mm
Max. tilt of loading plate
6 degrees
6 degrees
Storage temperature range
-30 to 70°C
(-20 to 160°F)
-30 to 70°C
(-20 to 160°F)
Operating temperature range
-10 to 50°C
(14 to 122°F)
-10 to 50°C
(14 to 122°F)
