Eaton EDR 3000 User Manual

EDR-3000 IM02602003E
Switch Onto Fault Module Input States
Name Description Assignment via
ExBlo1-I Module Input State: External Blocking [Protection Para
/Global Prot Para
/SOTF]
ExBlo2-I Module Input State: External Blocking [Protection Para
/Global Prot Para
/SOTF]
Rvs Blo-I Module Input State: Reverse Blocking [Protection Para
/Global Prot Para
/SOTF]
Ext SOTF-I Module Input State: External Switch Onto Fault Alarm [Protection Para
/Global Prot Para
/SOTF]
Signals of the Switch Onto Fault Module (Output States)
Signal Description
Active Signal: Active
ExBlo Signal: External Blocking
Rvs Blo Signal: Reverse Blocking
enabled Signal: Switch Onto Fault enabled. This Signal can be used to modify Overcurrent Protection
Settings.
AR Blo Signal: Blocked by AR
I< Signal: No Load Current.
www.eaton.com 498
