Eaton EDR 3000 User Manual

EDR-3000 IM02602003E
Parameter Description Setting range Default Menu path
t-D1 Dead time between trip and reclosure attempt. Can be
initiated either by a phase or a ground fault.
Only available if: Shots = 1-6
0.01 - 9999.00s 1s [Protection Para
/<1..4>
/AR
/Shot Manager
/Shot 1]
t-D2 Dead time between trip and reclosure attempt. Can be
initiated either by a phase or a ground fault.
Only available if: Shots = 2-6
0.01 - 9999.00s 1s [Protection Para
/<1..4>
/AR
/Shot Manager
/Shot 2]
t-D3 Dead time between trip and reclosure attempt. Can be
initiated either by a phase or a ground fault.
Only available if: Shots = 3-6
0.01 - 9999.00s 1s [Protection Para
/<1..4>
/AR
/Shot Manager
/Shot 3]
t-D4 Dead time between trip and reclosure attempt. Can be
initiated either by a phase or a ground fault.
Only available if: Shots = 4-6
0.1 - 9999.00s 1s [Protection Para
/<1..4>
/AR
/Shot Manager
/Shot 4]
t-D5 Dead time between trip and reclosure attempt. Can be
initiated either by a phase or a ground fault.
Only available if: Shots = 5-6
0.01 - 9999.00s 1s [Protection Para
/<1..4>
/AR
/Shot Manager
/Shot 5]
t-D6 Dead time between trip and reclosure attempt. Can be
initiated either by a phase or a ground fault.
Only available if: Shots = 6
0.01 - 9999.00s 1s [Protection Para
/<1..4>
/AR
/Shot Manager
/Shot 6]
t-ManualCloseBlock This timer will be started if the Breaker was switched on
manually. While this timer is running, AR cannot be
started.
0.01 - 9999.00s 10.0s [Protection Para
/<1..4>
/AR
/General Settings]
www.eaton.com 526
