Eaton EDR 3000 User Manual

EDR-3000 IM02602003E
Parameter Description Setting range Default Menu path
t-Lock2Ready This timer is started by the lockout reset signal, and
before the timer expire the AR cannot go to any other
state.
0.01 - 9999.00s 10.0s [Protection Para
/<1..4>
/AR
/General Settings]
t-Run2Ready Examination Time: If the Breaker remains after an
reclosure attempt (shot) for the duration of this timer in
the Closed position, the AR has been successful and the
AR module returns into the ready state.
0.01 - 9999.00s 10.0s [Protection Para
/<1..4>
/AR
/General Settings]
t-Block2Ready The release (de-blocking) of the AR will be delayed for
this time, if there is no blocking signal anymore.
0.01 - 9999.00s 10.0s [Protection Para
/<1..4>
/AR
/General Settings]
t-AR Supervision AR Overall supervision time (> sum of all the timers used
by AR)
1.00 - 9999.00s 100.0s [Protection Para
/<1..4>
/AR
/General Settings]
Service Alarm 1 As soon as the AR-Counter exceeds this number of
reclosure attempts, an alarm will be given out
(overhauling of the Bkr)
1 - 65535 1000 [Protection Para
/<1..4>
/AR
/AR Wear Superv]
Service Alarm 2 Too many auto reclosure attempts. If the parameterized
number of AR cycles is reached, an alarm will be given
out.
1 - 65535 65535 [Protection Para
/<1..4>
/AR
/AR Wear Superv]
Max AR/h Maximum Number of permitted Autoreclosure Cycles per
hour.
1 - 20 10 [Protection Para
/<1..4>
/AR
/AR Wear Superv]
Initiate AR:
InitiateFc1
Initiate Auto Reclosure : Initiate Function Start fct -.- [Protection Para
/<1..4>
/AR
/Shot Manager
/Initiate AR]
www.eaton.com 527
