Eaton EDR 3000 User Manual

EDR-3000 IM02602003E
Parameter Description Setting range Default Menu path
Angle IB Fund. Start Position respectively Start Angle of the Current
Phasor during Post phase: Phase B
-360 - 360° 240° [Service
/Test Mode (Prot
inhibit)
/WARNING! Cont?
/Sgen
/Configuration
/PostFault
/CT]
Angle IC Fund. Start Position respectively Start Angle of the Current
Phasor during Post phase: Phase C
-360 - 360° 120° [Service
/Test Mode (Prot
inhibit)
/WARNING! Cont?
/Sgen
/Configuration
/PostFault
/CT]
Angle IX meas
Fund.
Start Position respectively Start Angle of the Current
Phasor during Post phase: IX
-360 - 360° 0° [Service
/Test Mode (Prot
inhibit)
/WARNING! Cont?
/Sgen
/Configuration
/PostFault
/CT]
www.eaton.com 638
