States of the Inputs of the Failure Simulator
Name Description Assignment via
Ex Start Simulation-I State of the module input:External Start of Fault Simulation (Using
the test parameters)
[Service
/Test Mode (Prot inhibit)
/WARNING! Cont?
/Sgen
/Process]
ExBlo Module Input State: External Blocking [Service
/Test Mode (Prot inhibit)
/WARNING! Cont?
/Sgen
/Process]
Ex ForcePost-I State of the module input:Force Post state. Abort simulation. [Service
/Test Mode (Prot inhibit)
/WARNING! Cont?
/Sgen
/Process]
Signals of the Failure Simulator (States of the Outputs)
Signal Description
Running Signal: Measuring value simulation is running
State Signal: Wave generation states: 0=Off, 1=PreFault, 2=Fault, 3=PostFault, 4=InitReset
Direct Commands of the Failure Simulator
Parameter Description Setting range Default Menu path
Start Simulation Start Fault Simulation (Using the test parameters) Inactive,
Active
Inactive [Service
/Test Mode (Prot
inhibit)
/WARNING! Cont?
/Sgen
/Process]
www.eaton.com 639
