Hardware specifi cation
POWERXL SERIES VFD MN040010EN—June 2018 www.eaton.com
Vendor parameters object, class 0xA0~0xBB
PowerXL DG1 shall support Vendor Parameters Object, Class 0xA0 through 0xBB as given
in table below. Vendor Parameter object is used in order to get access to drive parameters.
Please refer to Appendix A for Class, Instance and Attribute values for each parameter.
Table 178. Vendor parameters object, class 0xA0, 0xA1, 0xA2, 0xA3, ---- 0xBB
Object descriptions
Class attributes
ID Description NV Data type Access rule Remarks/Default
01h Revision NV UINT Get 1
02h Max Instance NV UINT Get 1
03h Number of Instances NV UINT Get Varies for different objects
Class services
ID Service
0Eh Get_attribute_single
Instance attribute
ID Description Access rule
Varies for different objects
Instance services
ID Service
0Eh Get_attribute_single
10h Set_attribute_single
