Eaton PowerXL Series - Table 206. DH1 Parameter ID List

205
Appendix A—Parameter ID list
POWERXL SERIES VFD MN040010EN—June 2018 www.eaton.com
Table 206. DH1 Parameter ID list
Menu Item
No.
Modbus
Register
PROFIBUS
Parameter Description
Data
Type
Length
(in Bytes)
Display
FormatPNU
PNU
SubIndex
M1.1 1 502 0 Output Frequency INTEGER 2 x100
M1.2 24 1 0 Freq Reference INTEGER 2 x100
M1.3 2 503 0 Motor Speed INTEGER 2 x0
M1.4 3 504 0 Motor Current INTEGER 2 x10
M1.5 4 507 0 Motor Torque INTEGER 2 x10
M1.6 5 513 1 Motor Power INTEGER 2 x10
M1.7 6 501 0 Motor Voltage INTEGER 2 x10
M1.8 7 501 1 DC-link Voltage INTEGER 2 x0
M1.9 8 822 6 Unit Temperature INTEGER 2 x10
M1.10 9 822 4 Motor Temperature INTEGER 2 x10
M1.11 28 NA NA Latest Fault Code BYTE 1 x0
M1.12 1686 NA NA Instant Motor Power DOUBLE 4 x1000
M1.13 583 790 0 RTC Battery Status BYTE 1 x0
M2.1 10 560 0 Analog Input 1 INTEGER 2 x100
M2.2 11 560 1 Analog Input 2 INTEGER 2 x100
M2.3 25 570 0 Analog Output 1 INTEGER 2 x100
M2.4 575 570 1 Analog Output 2 INTEGER 2 x100
M2.5 12 760 0 DI1, DI2, DI3 BYTE 1 x0
M2.6 13 760 1 DI4, DI5, DI6 BYTE 1 x0
M2.7 576 760 2 DI7, DI8 BYTE 1 x0
M2.8 14 754 0 DO1,Virtual RO1,Virtual RO2 BYTE 1 x0
M2.9 557 762 0 RO1, RO2, RO3 BYTE 1 x0
M3.1 27 580 0 PT100 Temperture INTEGER 2 x10
M4.1 2120 NA NA Energy Savings DOUBLE 4 x1000
M5.1 2209 NA NA Control Board DIDO Status INTEGER 2 x0
M5.2 2210 NA NA SlotA DIDO Status INTEGER 2 x0
M5.3 2211 NA NA SlotB DIDO Status INTEGER 2 x0
M5.4 29 NA NA Application Status Word INTEGER 2 x0
M5.5 2414 NA NA Standard Status Word INTEGER 2 x0
M6.1 16 2150 0 PID1 Set Point DOUBLE 4 x100
M6.2 18 2864 0 PID1 Feedback DOUBLE 4 x100
M6.3 20 2167 0 PID1 Error Value DOUBLE 4 x100
M6.4 22 2124 0 PID1 Output INTEGER 2 x100
M6.5 23 2133 0 PID1 Status BYTE 1 x0
M6.6 32 2150 1 PID2 Set Point DOUBLE 4 x100
M6.7 34 2864 1 PID2 Feedback DOUBLE 4 x100
M6.8 36 2167 1 PID2 Error Value DOUBLE 4 x100
M6.9 38 2124 1 PID2 Output INTEGER 2 x100
M6.10 39 2133 1 PID2 Status BYTE 1 x0
M7.1 558 763 0 TC1, TC2, TC3 BYTE 1 x0
M7.2 559 3125 0 Interval 1 BOOLEAN 1 x0
M7.3 560 3125 1 Interval 2 BOOLEAN 1 x0
M7.4 561 3125 2 Interval 3 BOOLEAN 1 x0
M7.5 562 3125 3 Interval 4 BOOLEAN 1 x0
M7.6 563 3125 4 Interval 5 BOOLEAN 1 x0
M7.7 569 3101 0 Timer 1 DOUBLE 4 x0
M7.8 571 3101 1 Timer 2 DOUBLE 4 x0
M7.9 573 3101 2 Timer 3 DOUBLE 4 x0
M8.1 2445 NA NA Output DOUBLE 4 x100
M8.2 2447 NA NA Reference DOUBLE 4 x100
M9.1 601 520 2 Total MWh Count DOUBLE 4 x10000
