Eaton PowerXL Series - Table 191. Profile 1: Output Bytes 0 and 1

159
SmartWire-DT External Communication Cards
POWERXL SERIES VFD MN040010EN—June 2018 www.eaton.com
Profile 1 (8 bit): Outputs (Control)
Table 191. Profile 1: Output bytes 0 and 1
Byte Bit Designation Meaning
0
0FWD
Start Reverse
A value of 1 will start the variable frequency drive in the clockwise operating direction
1REV
Start anticlockwise operation
A value of 1 will start the variable frequency drive in the anticlockwise operating direction
2EN_Op
Enable operation
0: Stop (immediate disconnection of the output)
1: Operation
If this bit has a value of 0, the variable frequency drive’s output will be switched off directly. To start the device, this bit must be
set to a value of 1 and the FWD or REV bit must be set to 1 as well
3FaultAck
Fault Acknowledge
0: Do not acknowledge current fault
1: Acknowledge current fault (rising edge: 0 1)
This bit can be used to reset a fault in the variable frequency drive. The fault acknowledge function will only respond to a rising
edge, i.e., to the value changing from 0 to 1.
4I4 (Input 1)
Programmable input 1
Reserved – not used as of this writing
5I5 (Input 2)
Programmable input 2
Reserved – not used as of this writing
6I6 (Input 3)
Programmable input 3
Reserved – not used as of this writing
7I7 (Input 4)
Programmable input 4
Reserved – not used as of this writing
1 0-7 -- Reserved – not used as of this writing
Profile 2 (2 x 16 bit): Inputs (Status)
Table 192. Profile 2: Input bytes 0 to 4
Byte Bit Designation Meaning
0
0 -- Not used
1-- Not used
2.3
A1, A2 1-0-A-switch on DXG-NET-SWD
00 = Pos. A(utomatic)
01 = Pos. 0 (off)
10 = Pos. 0 (off)
11 = Pos. 1 (on)
4DIAG
0: no diagnostic alarm
1: Diagnostic alarm present
5-- Not used
6PRSNT
0: Device not present
1: Device present
7 -- Not used
