Eaton PowerXL Series - Figure 68. Smartwire-DT Parameter Menu; Smartwire-DT Parameters

154
SmartWire-DT External Communication Cards
POWERXL SERIES VFD MN040010EN—June 2018 www.eaton.com
SmartWire-DT parameters
Once the module is detected, following parameters can be
set on keypad for the SmartWire-DT
Figure 68. SmartWire-DT parameter menu
SWD parameters menu:
13:53
STP FWD KEY TPM
F: Fault
B: Optional Board
T: Favorite
Right/OK key
13:53
STP FWD KEY BOA
B19: Terminal: SWD
Right/OK key
REVERSE 13:53
STP FWD KEY BOA
B19.1: Monitor
B19.2: Parameters
B10: SlotB: No Board
REVERSE
BYPASS
JOG
MENU MENU
13:53
STP FWD KEY TPM
M: Monitor
P: Parameter
F: Fault
BYPASS
JOG
Down key until
Optional Board
Group
REVERSE 13:53
STP FWD KEY BOA
B19.2.1: SWD Card FB Fault Response
B19.2.5: Parameter Sets
MENU
B19.1.2: Parameter Access
Down key to set
Parameters,
Right/OK key
Up or Down
key to desired
parameter
