221
Appendix A—Parameter ID list
POWERXL SERIES VFD MN040010EN—June 2018 www.eaton.com
Menu Item
No.
Modbus
Register
PROFIBUS
Parameter Description
Data
Type
Length
(in Bytes)
Display
FormatPNU
PNU
SubIndex
O4 3 504 0 Motor Current INTEGER 2 x10
O5 4 507 0 Motor Torque INTEGER 2 x10
O6 5 513 1 Motor Power INTEGER 2 x10
O7 6 501 0 Motor Voltage INTEGER 2 x10
O8 7 501 1 DC-link Voltage INTEGER 2 x0
O9 8 822 6 Unit Temperature INTEGER 2 x10
O10 9 822 4 Motor Temperature INTEGER 2 x10
R11 141 1 8 Keypad Reference INTEGER 2 x100
R12 1307 2170 0 PID1 Keypad Set Point 1 DOUBLE 4 x100
R13 1309 2179 0 PID1 Keypad Set Point 2 DOUBLE 4 x100
142 256 0 Application BYTE 1 x0
340 323 0 Language BYTE 1 x0
566 3000 0 Real Time Clock BYTE 6 x0
582 3001 0 Daylight Saving BYTE 1 x0
101 20 0 Min Frequency INTEGER 2 x100
102 20 1 Max Frequency INTEGER 2 x100
486 210 0 Motor Nom Current INTEGER 2 x10
107 281 0 Current Limit INTEGER 2 x10
489 217 0 Motor Nom Speed INTEGER 2 x0
R13 490 215 0 Motor PF INTEGER 2 x100
487 211 0 Motor Nom Voltage INTEGER 2 x0
488 216 0 Motor Nom Frequency INTEGER 2 x100
103 130 0 Accel Time 1 INTEGER 2 x10
104 134 0 Decel Time 1 INTEGER 2 x10
1695 NA NA Hand Control Place BYTE 1 x0
136 436 0 Hand Reference BYTE 1 x0
135 408 0 Auto 1 Control Place BYTE 1 x0
137 437 0 Auto 1 Reference BYTE 1 x0
1297 2870 0 PID1 Process Unit BYTE 1 x0
1298 2871 0 PID1 Process Unit Min DOUBLE 4 x100
1300 2872 0 PID1 Process Unit Max DOUBLE 4 x100
1312 2110 0 PID1 Set Point 1 Source BYTE 1 x0
1307 2170 0 PID1 Keypad Set Point 1 DOUBLE 4 x100
1332 2112 0 PID1 Feedback 1 Source BYTE 1 x0
1333 2172 0 PID1 Feedback 1 Min INTEGER 2 x100
1334 2173 0 PID1 Feedback 1 Max INTEGER 2 x100
1297 2870 0 PID1 Process Unit BYTE 1 x0
1298 2871 0 PID1 Process Unit Min DOUBLE 4 x100
1300 2872 0 PID1 Process Unit Max DOUBLE 4 x100
1312 2110 0 PID1 Set Point 1 Source BYTE 1 x0
1307 2170 0 PID1 Keypad Set Point 1 DOUBLE 4 x100
1332 2112 0 PID1 Feedback 1 Source BYTE 1 x0
1333 2172 0 PID1 Feedback 1 Min INTEGER 2 x100
1334 2173 0 PID1 Feedback 1 Max INTEGER 2 x100
Table 206. DH1 Parameter ID list, continued
