Navigation buttons
The following navigation buttons on the home screen call the individual start pages of the
main menu functions:
Button Description
[ECOLAB
®
]
1
Opens the screen ‘System settings’ where the user can make general system
settings.
Ä Chapter 8.3 ‘System settings’ on page 56
[Archive]
2
Opens the screen ‘Archiv V
iew’ for viewing daily, monthly and annual reports.
Ä Chapter 8.5 ‘Accessing reports’ on page 73
[Parameter circ.]
3
Opens the screen ‘parameter: Area selection’ for configuring the installed
components of the Plant.
Ä Chapter 8.7 ‘Set up the lubrication circuits’ on page 79
[Param. Generally]
4
Opens the screen ‘Param. Generally
’ for viewing and adjusting the operating
parameters of the components installed in the Plant.
Ä Chapter 8.6 ‘Set the operating parameters’ on page 75
[Stat. ON/OFF]
5
Opens the screen ‘Statistic’ , which shows the date and time of the last system
shutdowns (
Start) and when power returned (End :).
Ä Chapter 8.4 ‘Statistics’ on page 72
[Message]
6
Opens the screen ‘Fault messages
’ with all alarms that are currently pending.
Ä Chapter 9.2 ‘Displaying faults’ on page 87
[Logout]
7
Pressing the button [Logout] resets all access permissions (the home screen remains
unchanged). T
o perform any further actions in the system, the PIN code for the
corresponding access level (user level) must be entered.
Ä ‘Password levels’ on page 54
