5 Structure
Details on the identification of the applicator station can be found on the
type plate
The nameplate is located on the outside left of the control cabinet. The
information on the nameplate is described in more detail in the
Ä Technical
data chapter.
In addition, there is a second nameplate inside the control cabinet. This
nameplate is used to identify the electrical design, including the software
version. In case of enquiries, the information on this nameplate must also be
specified.
Ä ‘Product designation / rating plate’ on page 96
Control cabinet - operator view
1
2
3
4
Fig. 3: DryExx
®
Advanced-ETH control unit
1
Control unit operating panel
2
White signal LED: power "ON"® Control unit in use
(lights blue)
3
Blue LED button: "fault reset"® fault (lights blue)
4
Main switch
A more detailed description of the control unit is provided in the sections
Ä Function description and Ä Software description .
The DryExx
®
system comes with a detailed wiring diagram.
