7.2.4 Bleed the lubrication circuits and check the system for correct operation
Personnel:
n
Manufacturer
n
Service personnel
Protective equipment:
n
Protective eyewear
n
Protective gloves
n
Safety shoes
Requirements:
n The valve assignment is complete.
n General parameters are set.
n Metering parameters are entered for all lubrication circuits
WARNING!
When filling the system with the dosing medium, it is essential to ensure that
no conveyor lubricant is allowed to drip onto the floor
.
1. Switch the control unit to ‘
System Manual’ operating mode.
Ä
Chapter 8.6.1 ‘Set the operating mode’ on page 76
2. In "Manual" mode, check the correct functioning of the digital inputs and outputs
according to the circuit diagram.
Ä
Chapter 8.3.3 ‘Check signals’ on page 63
3. In "Manual" mode, activate the lubrication circuit to be bled until track lubricant
escapes from the corresponding nozzles.
Ä
Chapter 8.3.3.2 ‘Check the digital outputs’ on page 66
Repeat the procedure with all lubrication circuit valves until the entire
distribution line system is filled with lubricant.
4. Check all system components and screw unions for leaks.
5. After putting the control unit into operation, test the installation. Adjust the control air
setting to create an optimal spray pattern.
The waiting time for actuating a lubrication circuit valve can be shortened
using the booster function on the control unit.
Ä
Chapter 8.7.2 ‘Set the
boost times’ on page 82
6. Follow-up tasks:
n When commissioning is complete, set the control unit to automatic mode.
Ä
Chapter 8.6.1 ‘Set the operating mode’ on page 76
n When handing over the system to the customer, set up access passwords.
Ä
Chapter 8.3.5 ‘Issue PIN codes’ on page 68
Commissioning / operation
46Ver. 08-04.2024
