Select a chemical from the database:
1.
[Main menu] :
Ä
Chapter 7.6 ‘Main menu’ on page 66
2.
[Configuration menu] :
Ä
Chapter 7.9 ‘Overview - Configuration’ on page 83
3. Scroll up to [Metering chemical] using the scrollbar along the right edge of the
screen.
4. [Metering chemical] - select.
ð
Screen switches to the setting for the [Metering chemical].
5. Option / Entry: In the example ‘F&B 2015-07-16’, press
6.
[ Press the Next button] .
ð
Display changes to the screen with the last [product name setting] . Here in the
example ‘F&B 2015-07-16’
7. Enter the [Metering chemical] that you require.
8.
After entering the first letter, the software conducts a search in the
background for the matching name and only offers the next possible
letters to choose from.
9.
Press the Next button.
ð
Display changes to the screen with the last [product name setting].
10.
Press the Next button.
ð
Screen switches to the [product name setting]
11. Enter the first letters of the metered chemical with the scrollbar as described in
Ä
Chapter 7.3.3 ‘Scroll bars, radio buttons, selection fields, number and text input’
on page 60.
It is sufficient here to enter the first letters of the required product name
as a search is made for a matching selection in the integrated database in
the subsequent steps.
12.
Press the Next button.
ð
Screen switches to the database entries which are identical to the letters entered.
13. Select the matching entry
.
14.
Press the button.
ð
The setting is saved, and the screen switches to Service info.
If you select a metering chemical from the integrated database, the
pump sets the service intervals automatically
Ä
Chapter
7.9.11 ‘Service interval’ on page 102.
15.
Press the button.
ð
All settings are saved, and the screen switches to the Configuration overview
.
16.
Pressing the button returns to the [Main menu].
17.
Pressing the button returns to the [Operating display].
Control / software
101 Rev. 2-05.2018
