7.9.10.2 Manual input (manual)
Fig. 59: Configuration: Metered chemical - Manual
Set [Manual:]
1.
Call up the[Main menu]:
Ä Chapter 7.6 ‘Main menu’ on page 66
2.
Select [Configuration]:
Ä Chapter 7.9 ‘Overview - Configuration’ on page 83
3. Scroll up to [Dosing chemical]
using the scrollbar along the right edge of the screen.
4. Select [Dosing chemical].
ð
Screen switches to the setting for the [Dosing chemical].
5. Option: Select ‘manual’
6.
Press the [Next] button.
ð
Screen switches to the setting for the [Product name].
7.
Enter the name of the metered chemical with the scrollbar as described in
Ä Chapter
7.3.3 ‘Scroll bars, radio buttons, selection fields, number and text input’ on page 60 .
8.
Press the button.
ð
The setting is saved, and the screen switches to the configuration overview
.
9.
Press the button.
ð
The screen switches to the [main menu.]
10.
Press the button.
ð
The pump switches back to the operation screen.
