Ecolab EcoAdd

1.
[Main menu] :
Ä Chapter 7.6 ‘Main menu’ on page 66
2.
[Configuration menu] :
Ä Chapter 7.9 ‘Overview - Configuration’ on page 83
3. Scroll up to [Operating data] using the scrollbar along the right edge of the screen.
4. [Operating data]
- select
ð
The screen changes to [Operating data].
5. Select the required ‘operating data’:
n Quantity
n Motor runtime
n Changing the container
n Alarms
n Service
n Calibration
n Pulse
n Reset?
ð
Screen changes to the required ‘operating data’.
6. If the ‘Operating data’ ‘reset?’
menu option is selected, a red screen is displayed.
There are two function keys located in the header.
Pressing the
button cancels the reset operation.
The data remains unchanged.
ð
Screen changes back to the overview of the ‘operating data’
7.
Press the button to delete all the operating data that has been saved up to that
point.
ð
Screen changes back to the overview of the ‘operating data’
8.
Pressing the button returns to the [Main menu].
9.
Pressing the button returns to the [Operating display].
7.12 Info
Fig. 78: Info
Display the [Info] selection:
1.
Call up the [Main menu]:
Ä Chapter 7.6 ‘Main menu’ on page 66
2.
Select the [configuration:] Ä Chapter 7.9 ‘Overview - Configuration’ on page 83
ð
Screen switches to the [Configuration] selection level.
3. Scroll to [Info] using the scrollbar along the right edge of the screen.
4. Select [Info]
ð
Screen switches to the [Info] screen and displays all the specific pump data.
5.
Pressing the button returns to the [Main menu].
6.
Pressing the button returns to the [Operating display].
Control / software
121 Rev. 2-05.2018
