7.6.2 Open the main menu with the access code activated
Fig. 30: Calling up the main menu with an access code
1.
[Open main menu] by pressing the [Menu button] .
ð
The screen switches to query the [access code].
2.
The activated [access code] is shown by the padlock symbol !
3. [access code]
using the scroll bar
(range: A-Z, 0-9, and various special characters).
4.
Press the Next
button.
ð
The screen switches to the overview: [Main menu].
5. Use the [scrollbar] on the right-hand side of the screen to scroll to the required
setting and select it.
6.
Press the
button to exit the [Main menu] again. The pump switches back to the
operation screen.
If you enter an incorrect access code, the locked menu item remains inactive
and is "greyed out". The menu option only becomes active and available for
selection when the access code has been entered successfully
.
If the access code is no longer known, it can be reset as described in
Ä
Chapter 7.9.4.2 ‘What can I do if I forget the access code?’ on page 90.
7.7 Metering mode
Selecting a corresponding [Metering mode] (
/ / / ) makes it possible to extend the
suction duration per stroke (suction stroke duration) and thus adjust the metering to high
product viscosities or challenging suction conditions.
This extension of the suction stroke duration simultaneously results in a reduction in the
max. metering output (see tables below).
Control / software
67 Rev. 2-05.2018
