7.9.16.2 Exporting a configuration
Fig. 75: Exporting a configuration
1.
Press the Menu button .
ð
The [Main menu] is opened.
2. Insert the USB stick containing the configuration into the USB port on the pump
ð
The pump recognises the USB stick and opens the menu for importing and
exporting databases.
3. In the [Main menu] ‘Select configuration’.
4. [USB export] - select.
ð
The screen displays the active export process of the configuration file via a rolling
circle.
Once the export process is complete, the screen switches back to the menu for
importing and exporting the configuration.
5.
Pressing the button returns to the [Main menu].
6.
Pressing the button returns to the [Operating display].
The exported configuration is located on the USB stick at the path:
/ECOADD/EXPORT
Control / software
117 Rev. 2-05.2018
