9.8.1.3.1 [Operating mode] [Power] [variable]
Fig. 106: [Operating mode] [Power] [variable]
[Operating mode] - [Power] - setting:
1.
[Main menu] :
Ä Chapter 7.6 ‘Main menu’ on page 66
2. [Operating mode] - [Power]
- select.
3.
[ Press the Next button] .
ð
Screen change for the power setting:
4. Open the next menu options using the scroll bar
.
5. Select the [variable] - select.
6.
Press the Next button.
ð
Screen change for the power setting [Current limit 1].
7. ‘mA
’ in the decimal places using the scrollbar.
8. Select the field for entering the value after the decimal point.
ð
The colour changes to dark blue, which indicates that the field is ready for the
entry
.
9. Set the decimal point with the scrollbar
.
10.
Press the Next button.
ð
Screen change for the power setting [Current limit 2].
11. ‘mA
’ in the decimal places using the scrollbar.
12. Select the field for entering the value after the decimal point.
ð
The colour changes to dark blue, which indicates that the field is ready for the
entry
.
13. Set the decimal point with the scrollbar.
14.
Press the button.
ð
Settings are saved, and the screen returns to the overview: [Power].
15.
Press the button to return to the menu: [Operating mode].
16.
Pressing the button returns to the [Main menu].
17.
Pressing the button returns to the [Operating display].
