9.4 Setting or changing the pump capacity in L
The following screens show example displays for a pump with capacity of
1
1 l/h. Specifications and information shown will differ for other pump sizes.
Fig. 93: Changing the pump capacity in L during ongoing operation
Set or change the pump capacity in L:
1. On the operation screen, press the displayed ‘capacity in L
’:
To access the settings, press and hold the displayed ‘capacity in L’ for
around 3 seconds.
2. If a password prompt is not displayed, you can skip this step.
If the [access code] is enabled , please note the following:
Ä
Chapter 7.6 ‘Main menu’ on page 66.
NOTICE!
W
e strongly advise that you enable the security settings.
Ä
Chapter 7.9.4 ‘Access code’ on page 88
ð
The screen switches to the screen for setting the ‘capacity in L
’.
3. Use the scrollbar to set the ‘capacity in L
’ before the decimal point.
4. Select the field for entering the value after the decimal point.
ð
The colour changes to dark blue, which indicates that the field is ready for input.
5. Use the scrollbar to set the ‘capacity in L
’ after the decimal point.
6.
Press the button.
ð
The pump saves the settings and switches back to the operation screen. The
operation screen shows the new ‘capacity in L
’.
Operation
139 Rev. 2-05.2018
