Symbol Description
Metering release
Metering release is activated.
Calibration
Notice to perform a calibration of the pump!
Oval gear meter - OGM
An oval gear meter (OGM) is connected to the pump.
Select Batch
Display of the [Select Batch]operation
Ä
Chapter 7.9.12 ‘Select Batch’ on page 104.
Chemistry database is installed.
A database with specific chemical data has been installed and is available for selection in the
configuration.
Pulse memory
The memory for incoming pulses is available.
Operation
138Rev. 2-05.2018
