13.4 General data
Name
Type
00510X
Type
01
110S
Type
03003M
Type
05010M
Type
12003M
Max. metering capacity [l/h]
1)
Metering mode [S] 5 11 30 50 120
Metering mode [M] 4,2 9,2 25 41,7 100
Metering mode [L] 3,3 7,3 20 33,3 80
Min. metering capacity [l/h] 0,05 0,11 0,30 0,50 1,2
Max. metering back-pressure [MPa (bar)] 0,1 (10) 0,03 (3) 1 (10) 0,03 (3)
Max. stroke frequency [1/min]
2)
Metering mode [S] 171 160 162 164
Metering mode [M] 143 133 135 137
Metering mode [L] 114 107 108 109
Metering quantity per stroke [ml] 50 Hz/60 Hz
2)
0,53 1,04 3,16 5,74 13,51
Reproduction accuracy [%] < ±
3
max. conveyable viscosity
[mPas] with valves:
Standard 200 100 200 100
spring-loaded with
metering mode [S]
500 250 500 250
spring-loaded with
metering mode [L]
1000 500 1000 500
Permissible ambient
temperature [°C]
3)
2 - 45
max. suction height [mWs]
3)
V
iscosity:
up to 50 mPas 2
over 50 mPas 1
max. suction line length [m]
V
iscosity:
up to 50 mPas 3
over 50 mPas 2
max. suction-side pre-pressure [MPa (bar)] 0,2 (2) 0,1 (1) 0,2 (2) 0,1 (1)
Max. differential pressure suction and pressure side
[MPa (bar)]
0,1 (1) 0,05 (0,5) 0,1 (1) 0,05 (0,5)
Min. hose Ø [mm] suction side;
viscosity:
up to 50 mPas
4
5 6 12
over 50 mPas 9 12 19
min. hose Ø [mm] pressure
side; viscosity:
up to 50 mPas
5
5 6 9
over 50 mPas 6 9 12
Noise level (DBA) at a distance of 1m
(according to DIN EN 12639/ EN ISO 9614-2)
< 60
Weight [kg] 3,1 3,8 5,2 5,7
Approvals CE
1) V
alues determined with water as the metering medium at a temperature of 20°C.
2) Values vary depending on calibration.
3) Suction height determined with clean, moistened valves at maximum stroke frequency.
4) Measurement in the MK240 heating cabinet.
Technical data
188Rev. 2-05.2018
