Ecolab EcoAdd

Step two: Activate dosing release
Fig. 82: Software setting: ‘Dosing release’
1.
[Main menu] Press the button.
ð
The ‘Main menu’ screen is displayed.
2. [Configuration menu] - select.
ð
Menu [Configuration menu] is displayed.
3. Use the scrollbar to go to the [Dosing release] using the scrollbar along the right
edge of the screen.
4. [Dosing release] - select.
ð
The screen for setting the [Dosing release] is displayed.
5. [Dosing release] - select.
ð
If the [Dosing release] is activated (closed contact),
a ü is displayed in the selection box.
6.
Pressing the button saves and returns to the [Configuration menu].
7.
Pressing the button returns to the [Main menu].
8.
Pressing the button returns to the [Operating display].
Commissioning
126Rev. 2-05.2018
