1.
[Main menu] :
Ä
Chapter 7.6 ‘Main menu’ on page 66
2. [Operating mode] - [T
imer] - select.
3.
[Press the Next button] .
ð
Screen change to the selection of the timer interval (weekly programme)
4. [Seven-day programme] - select.
ð
Screen change to the selection of the ‘T
ime’ - [Seven-day programme]
5. Select timing (up to seven dif
ferent weekly programmes are possible)
ð
The screen changes to the setting ‘Timer 1’: ‘Switching point’
6.
Press the button to close the weekly programme without saving.
ð
The screen switches back to the [Operating mode] .
7. Use the scrollbar to set the time/hours.
8. select time / minutes.
9. Use the scrollbar to set the time/minutes.
10.
Press the Next button.
ð
Screen change for setting: ‘Pulse duty factor
’
11. Use the scrollbar to set the minutes.
12. Select seconds.
13. Use the scrollbar to set the seconds.
14.
Press the Next button.
ð
Screen change for setting: ‘Capacity’
15. ‘Set the decimal places of the capacity in litres’ using the scroll bar
.
16. Select the field for entering the value after the decimal point.
ð
The colour changes to dark blue, which indicates that the field is ready for the
entry
.
17. ‘Set decimal places of the capacity in litres’ using the scrollbar
.
18.
Press the Next button.
ð
Screen change for setting: ‘day of the week’
19. ‘Select the days of the week’
ð
A check mark is set in the selection field.
20.
Press the button.
ð
The pump saves the settings and switches back to the previous screen.
21.
Pressing the button returns to the [Main menu].
22.
Pressing the button returns to the [Operating display].
Control / software
81 Rev. 2-05.2018
