Edge-Core AS7326-56X Programming Guide

EDGECORE NETWORKS CORPORATION 2018
156
5
Port51_LED2_Active_B
(P51_Lane1_LED_B)
R/W
0
1: Port51_LED2_B Active ON
0: Port51_LED2_B Active OFF (Default)
4
Port51_LED2_Active_G
(P51_Lane1_LED_G)
R/W
0
1: Port51_LED2_G Active ON
0: Port51_LED2_G Active OFF (Default)
3
Port51_LED2_Active_R
(P51_Lane1_LED_R)
R/W
0
1: Port51_LED2_R Active ON
0: Port51_LED2_R Active OFF (Default)
2
Port51_LED2_B
(P51_Lane1_LED_B)
R/W
1
1: Port51_LED2_B LED OFF (Default)
0: Port51_LED2_B LED ON
1
Port51_LED2_G
(P51_Lane1_LED_G)
R/W
1
1: Port51_LED2_G LED OFF (Default)
0: Port51_LED2_G LED ON
0
Port51_LED2_R
(P51_Lane1_LED_R)
R/W
1
1: Port51_LED2_R LED OFF (Default)
0: Port51_LED2_R LED ON
5.12.6.23. Offset 0x3A QSFP28 RGB LED -11 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port51_LED3_Active_B
(P51_Lane2_LED_B)
R/W
0
1: Port51_LED3_B Active ON
0: Port51_LED3_B Active OFF (Default)
4
Port51_LED3_Active_G
(P51_Lane2_LED_G)
R/W
0
1: Port51_LED3_G Active ON
0: Port51_LED3_G Active OFF (Default)
3
Port51_LED3_Active_R
(P51_Lane2_LED_R)
R/W
0
1: Port51_LED3_R Active ON
0: Port51_LED3_R Active OFF (Default)
2
Port51_LED3_B
(P51_Lane2_LED_B)
R/W
1
1: Port51_LED3_B LED OFF (Default)
0: Port51_LED3_B LED ON
1
Port51_LED3_G
(P51_Lane2_LED_G)
R/W
1
1: Port51_LED3_G LED OFF (Default)
0: Port51_LED3_G LED ON
0
Port51_LED3_R
(P51_Lane2_LED_R)
R/W
1
1: Port51_LED3_R LED OFF (Default)
0: Port51_LED3_R LED ON
5.12.6.24. Offset 0x3B QSFP28 RGB LED -12 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port51_LED4_Active_B
(P51_Lane3_LED_B)
R/W
0
1: Port51_LED4_B Active ON
0: Port51_LED4_B Active OFF (Default)
4
Port51_LED4_Active_G
(P51_Lane3_LED_G)
R/W
0
1: Port51_LED4_G Active ON
0: Port51_LED4_G Active OFF (Default)
3
Port51_LED4_Active_R
(P51_Lane3_LED_R)
R/W
0
1: Port51_LED4_R Active ON
0: Port51_LED4_R Active OFF (Default)
2
Port51_LED4_B
(P51_Lane3_LED_B)
R/W
1
1: Port51_LED4_B LED OFF (Default)
0: Port51_LED4_B LED ON
