Edge-Core AS7326-56X Programming Guide

EDGECORE NETWORKS CORPORATION 2018
158
5
Port52_LED3_Active_B
(P52_Lane2_LED_B)
R/W
0
1: Port52_LED3_B Active ON
0: Port52_LED3_B Active OFF (Default)
4
Port52_LED3_Active_G
(P52_Lane2_LED_G)
R/W
0
1: Port52_LED3_G Active ON
0: Port52_LED3_G Active OFF (Default)
3
Port52_LED3_Active_R
(P52_Lane2_LED_R)
R/W
0
1: Port52_LED3_R Active ON
0: Port52_LED3_R Active OFF (Default)
2
Port52_LED3_B
(P52_Lane2_LED_B)
R/W
1
1: Port52_LED3_B LED OFF (Default)
0: Port52_LED3_B LED ON
1
Port52_LED3_G
(P52_Lane2_LED_G)
R/W
1
1: Port52_LED3_G LED OFF (Default)
0: Port52_LED3_G LED ON
0
Port52_LED3_R
(P52_Lane2_LED_R)
R/W
1
1: Port52_LED3_R LED OFF (Default)
0: Port52_LED3_R LED ON
5.12.6.28. Offset 0x3F QSFP28 RGB LED -16 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port52_LED4_Active_B
(P52_Lane3_LED_B)
R/W
0
1: Port52_LED4_B Active ON
0: Port52_LED4_B Active OFF (Default)
4
Port52_LED4_Active_G
(P52_Lane3_LED_G)
R/W
0
1: Port52_LED4_G Active ON
0: Port52_LED4_G Active OFF (Default)
3
Port52_LED4_Active_R
(P52_Lane3_LED_R)
R/W
0
1: Port52_LED4_R Active ON
0: Port52_LED4_R Active OFF (Default)
2
Port52_LED4_B
(P52_Lane3_LED_B)
R/W
1
1: Port52_LED4_B LED OFF (Default)
0: Port52_LED4_B LED ON
1
Port52_LED4_G
(P52_Lane3_LED_G)
R/W
1
1: Port52_LED4_G LED OFF (Default)
0: Port52_LED4_G LED ON
0
Port52_LED4_R
(P52_Lane3_LED_R)
R/W
1
1: Port52_LED4_R LED OFF (Default)
0: Port52_LED4_R LED ON
5.12.6.29. Offset 0x40 QSFP28 RGB LED -17 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port53_LED1_Active_B
(P53_Lane3_LED_B)
R/W
0
1: Port53_LED1_B Active ON
0: Port53_LED1_B Active OFF (Default)
4
Port53_LED1_Active_G
(P53_Lane3_LED_G)
R/W
0
1: Port53_LED1_G Active ON
0: Port53_LED1_G Active OFF (Default)
3
Port53_LED1_Active_R
(P53_Lane3_LED_R)
R/W
0
1: Port53_LED1_R Active ON
0: Port53_LED1_R Active OFF (Default)
2
Port53_LED1_B
(P53_Lane3_LED_B)
R/W
1
1: Port53_LED1_B LED OFF (Default)
0: Port53_LED1_B LED ON
