EDGECORE NETWORKS CORPORATION 2018
99
7
Present* P38 SFP28
(SFP+_MOD_ABS_P39)
R
1
1: No transceiver
0: transceiver had plugged
6
Present* P37 SFP28
(SFP+_MOD_ABS_P38)
R
1
1: No transceiver
0: transceiver had plugged
5
Present* P36 SFP28
(SFP+_MOD_ABS_P35)
R
1
1: No transceiver
0: transceiver had plugged
4
Present* P35 SFP28
(SFP+_MOD_ABS_P33)
R
1
1: No transceiver
0: transceiver had plugged
3
Present* P34 SFP28
(SFP+_MOD_ABS_P34)
R
1
1: No transceiver
0: transceiver had plugged
2
Present* P33 SFP28
(SFP+_MOD_ABS_P30)
R
1
1: No transceiver
0: transceiver had plugged
1
Present* P32 SFP28
(SFP+_MOD_ABS_P36)
R
1
1:No transceiver
0: transceiver had plugged
0
Present* P31 SFP28
(SFP+_MOD_ABS_P29)
R
1
1: No transceiver
0: transceiver had plugged
5.12.2.18. Offset 0x11 Module Present-2 (Read Only)
Bit
Name
R/W
Reset Value
Description
7
Present* P46 SFP28
(SFP+_MOD_ABS_P47)
R
1
1: No transceiver
0: transceiver had plugged
6
Present* P45 SFP28
(SFP+_MOD_ABS_P43)
R
1
1: No transceiver
0: transceiver had plugged
5
Present* P44 SFP28
(SFP+_MOD_ABS_P45)
R
1
1: No transceiver
0: transceiver had plugged
4
Present* P43 SFP28
(SFP+_MOD_ABS_P44)
R
1
1: No transceiver
0: transceiver had plugged
3
Present* P42 SFP28
(SFP+_MOD_ABS_P37)
R
1
1: No transceiver
0: transceiver had plugged
2
Present* P41 SFP28
(SFP+_MOD_ABS_P42)
R
1
1: No transceiver
0: transceiver had plugged
1
Present* P40 SFP28
(SFP+_MOD_ABS_P41)
R
1
1: No transceiver
0: transceiver had plugged
0
Present* P39 SFP28
(SFP+_MOD_ABS_P40)
R
1
1: No transceiver
0: transceiver had plugged
