Edwards STP-iX457 Series User Manual

STP-iX457/iXU457 Series Turbomolecular Pump
MT-86E-001-F
Page 117
5
SERIAL COMMUNICATION PROTOCOL
Parameter Item Data format Remarks
1
Input operation port setting 8-bits hexadecimal coded
ASCII
Default 01
hex
(I/O REMOTE)
2
*1
TMS Option
Enable/Disable setting
8-bits hexadecimal coded
ASCII
Default FF
hex
(DISABLE)
3
[System reservation] 8-bits hexadecimal
coded ASCII
*2
4
Vent valve
Enable/Disable setting
8-bits hexadecimal
coded ASCII
Default FF
hex
(DISABLE)
5
Vent valve starting speed setting 8-bits hexadecimal
coded ASCII
Default 32
hex
(50 %)
6
Vent valve running time setting 16-bits hexadecimal
coded ASCII
Default 003C
hex
(60 sec.)
7
Air-cooling fan
Enable/Disable setting
8-bits hexadecimal
coded ASCII
Default FF
hex
(DISABLE)
8
Second Damage Limit Option
Enable/Disable setting
8-bits hexadecimal
coded ASCII
Default 00
hex
(EN
ABLE)
9
First Damage Limit Warning
Enable/Disable setting
8-bits hexadecimal
coded ASCII
Default 00
hex
(ENABLE)
10
Pump Runtime Over Warning
Enable/Disable setting
8-bits hexadecimal
coded ASCII
Default FF
hex
(DISABLE)
11
Pump Runtime Over Warning
Hours setting (×100 hours)
32-bits hexadecimal
coded ASCII
Default
00000000
hex
12
Imbalance Warning
Enable/Disable setting
8-bits hexadecimal
coded ASCII
Default 00
hex
(ENABLE)
13
Pump Overload Warning
Enable/Disable setting
8-bits hexadecimal
coded ASCII
Default FF
hex
(DISABLE)
14
Pump Overload Warning
Motor current setting
16-bits hexadecimal
coded ASCII
Default 03E8
hex
(100.0%)
15
Pump Overload Warning
Rotational speed setting
16-bits hexadecimal
coded ASCII
Default 0000
hex
(0.0%)
16
Serial communication
time out setting (Unit: sec.)
16-bits hexadecimal
coded ASCII
Default 003C
hex
(60 sec.)
17
PROG OUT pin setting 8-bits hexadecimal
coded ASCII
Default 01
hex
(
ROTATION
)
18
PROG IN pin setting 8-bits hexadecimal
coded ASCII
Default 01
hex
(
RESET
)
19
[System reservation] 72-bits hexadecimal
coded ASCII
*2
*1 Valid only with TMS specification
*2 Assign the parameter value Fhex or the reading data of ReadOptionFunc (?=)
