1st - Bypass procedure with Progress disabled:
1. Contact an authorised service workshop to get the
password.
2. Navigate in the display panel on the User
Interface to the menu 'Crane settings - Utilities -
Emergency Function’.
3. Enter the password (eight digit numbers). 'Disable
All Level' is displayed to indicate the activation of
the emergency bypass.
4. Operate the crane only as an emergency
operation to bring the crane out of the emergency
situation or to the transport position.
5. Go to the 2nd procedure if the crane is still stopped.
NOTE
When you enter the password to disable all the control and safety systems on
the crane, Progress saves the date and the time in which you use the crane
with the safety systems disabled.
2nd - Bypass procedure with PROGRESS device off
Switch off Progress with the ON/OFF button on the User Interface.
FOR DANFOSS MAIN CONTROL VALVE
1. Remove the main control valve safety cover (A).
2. If fitted, activate the emergency operation of the main solenoid valve (B) by pushing the spool
and turning it clockwise until it is locked.
The knurled spool on the control valves has two positions:
(2a) lifted for normal operation.
(2b) lowered for emergency operation.
3. The shaft (C) may be provided with a knob (D) or with a hexagonal head screw.
4. Break the security seal (G) on the shaft (C).
Ending crane operation
134 EFFER 265-315-395-525 Progress 2.0 CE
