Effer 265 - Components of Progress 2.0; Standard Symbols and Functions of the Crane

DANGER
Never try to repair the control system yourself. Repairs may only be made by an
authorised service workshop!
4.3. Components of Progress 2.0
(1) Main control valve (4) User interface with
display panel [option]
(7) STEADY controller
[option]
(2) Stabiliser control
valve
(5) Stabiliser leg lamp
[option]
(8) SCANRECO controller
[option]
(3) User interface with
LEDs [option]
(6) Warning lamp
4.4. Standard symbols and functions of the crane
These symbols can be shown:
• On the control valve levers.
• On the controller (If delivered).
