Hooks with swivel
1. Lubricate with oil the spring of the latch.
2. If the hooks cannot rotate easily with load, grease the
swivel bearing.
Use a bearing grease, type "Texaco Multifak EP 2" or
equivalent quality.
8.5. Checking and topping up oil levels
8.5.1. Slewing motors gearbox
Supplier recommendation:
Have the oil changed approximately every 2500 operating hours.
Recommended oil:
Use a hypoid oil, type API GL-5, SAE J2360 (Formerly MIL-L-2105),viscosity SAE-80W-90,
cleanliness NAS 1638:8. For example: "ENI ROTRA MP 80W-90", “SHELL SPIRAX S2 A 80W/90”
or equivalent quality.
CAUTION
The oil used for filling must be clean. Do not mix different oils (a mixture will
change the oil properties).
Oil level checking and top up
1. Remove the plug (1).
2. Check if there is enough oil.
3. If there is no oil, top up with oil till it comes out of the
motor.
4. Mount the plug (1).
Maintenance and Service
EFFER 265-315-395-525 Progress 2.0 CE 155
